33 mm cabinet depth
Integrated die-cast aluminum construction helps reduce wall build-out while maintaining cabinet rigidity.
Indoor fixed LED display
Hardwired Super Thin Screen
A 33 mm die-cast aluminum cabinet platform for high-quality indoor LED walls. Front maintenance, flexible cabinet sizes and fast installation make it suitable for meeting rooms, retail, corporate and creative display projects.
Engineering highlights
Thin, serviceable and flexible.
Front maintenance
Service the display from the front where rear access is limited, helping reduce installation constraints.
Creative splicing
Available in 500, 750 and 1000 mm widths with 250 and 500 mm heights for flexible layouts.
Published brochure specifications
Technical overview
Pitch, brightness and scan mode vary by selected configuration. Confirm the final LED module and receiving-card specification before production.
| Pixel pitch | P1.25 / P1.56 / P1.95 / P2.5 / P2.604 / P2.976 / P3.91 |
| Cabinet sizes | 500×250, 750×250, 1000×250, 500×500, 750×500 and 1000×500 mm |
| Cabinet thickness | 33 mm |
| Cabinet material | Die-cast aluminum |
| Maintenance | Front access |
| Refresh rate | 3,840 Hz |
| Brightness | 600 nits for P1.25/P1.56; 800 nits for P1.95 and above, according to the brochure table |
| Viewing angle | 160° horizontal / 160° vertical |
| Protection | IP31 |
| Max power consumption | 350 W/m² |
Giantbull Hardwired Super Thin Screen brochureCabinet construction, installation modes and complete specification table
